Bright Nickel Alloy Wire Nimn2 Nickel Manganese Alloy Wire

Brand Name : TANKII

Model Number : NiMn2 / Ni212

Certification : ISO9001 SGS

Place of Origin : China

MOQ : 100 KG

Price : negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 Tons per month

Delivery Time : 7-20 days

Packaging Details : Spool + Carton + Wooned Case

Material : Nickel Manganin alloy wire

Diameter : 0.05-5mm

Surface : Bright

Origin : China

HS Code : 75052200

Standard : GB

type : wire ribbon tape

Name : NiMn2 NI212

Contact Now

NiMn2 Chemical composition

Item Chemicals composition: %
Ni+Co Cu Si Mn C Mg S Fe Pb Zn
NiMn2 ≥97 ≤0.20 ≤0.20 1.5~2.5 ≤0.05 ≤0.15 ≤0.01 ≤0.30 - -

NiMn2 Diameter and tolerance

Diameter Tolerance
>0.30~0.60 -0.025
>0.60~1.00 -0.03
>1.00~3.00 -0.04
>3.00~6.00 -0.05

NiMn2 mechanical property

Diameter Condition Tensile Strength ( MPA ) Elongation %
0.30~0.48 Soft ≥392 ≥20
0.5~1.00 ≥372 ≥20
1.05~6.00 ≥343 ≥25
0.30~0.50 Hard 784~980 -
0.53~1.00 686~833 -
1.05~5.00 539~686 -

Dimensions and delivery forms
Wires can be produced in diameters from 0.13 to 5.0 mm and can be delivered on plastic standard spools or in coils, depending on the wire size.
Applications
Largely used for its corrosion resistance for lamp filaments, filters, industrial and laboratory equipment. Often used as a resistor, when high variation of resistance at temperature is required.
Stranded Nickel wire finds applications in resistor terminations.
NiMn2
The addition of Mn to pure Nickel brings much improved resistance to Sulphur attach at elevated temperatures andimproves strength and hardness, without appreciable reduction of ductility.
NiMn2 is used as a support wire in incandescent lamps and for electrical resistor terminations.
Features
The company electrode material (conductive material) having a low resistivity, high temperature strength, the smaller the arc
melting under the action of evaporation and so on.

Bright Nickel Alloy Wire Nimn2 Nickel Manganese Alloy Wire
